- changed some status bar messages

- New feature: added the capability to view the source code of the Gerber/Excellon file that was loaded into the app. The file is also stored as an object attribute for later use. THe view option is in the project context menu and in Menu -> Options -> View Source

FlatCAMApp.py

@@ -92,8 +92,8 @@ class App(QtCore.QObject):
     log.addHandler(handler)

     # Version
-    version = 8.909
-    version_date = "2019/02/16"
+    version = 8.910
+    version_date = "2019/02/23"
     beta = True

     # current date now
@@ -1129,7 +1129,7 @@ class App(QtCore.QObject):

         self.ui.menuoptions_transform_flipx.triggered.connect(self.on_flipx)
         self.ui.menuoptions_transform_flipy.triggered.connect(self.on_flipy)
-
+        self.ui.menuoptions_view_source.triggered.connect(self.on_view_source)

         self.ui.menuviewdisableall.triggered.connect(self.disable_all_plots)
         self.ui.menuviewdisableother.triggered.connect(self.disable_other_plots)
@@ -1156,6 +1156,8 @@ class App(QtCore.QObject):
         self.ui.menuprojectenable.triggered.connect(lambda: self.enable_plots(self.collection.get_selected()))
         self.ui.menuprojectdisable.triggered.connect(lambda: self.disable_plots(self.collection.get_selected()))
         self.ui.menuprojectgeneratecnc.triggered.connect(lambda: self.generate_cnc_job(self.collection.get_selected()))
+        self.ui.menuprojectviewsource.triggered.connect(self.on_view_source)
+
         self.ui.menuprojectcopy.triggered.connect(self.on_copy_object)
         self.ui.menuprojectedit.triggered.connect(self.object2editor)

@@ -3934,7 +3936,7 @@ class App(QtCore.QObject):
                     obj.mirror('X', [px, py])
                     obj.plot()
                     self.object_changed.emit(obj)
-
+                self.inform.emit("[success] Flip on Y axis done.")
             except Exception as e:
                 self.inform.emit("[ERROR_NOTCL] Due of %s, Flip action was not executed." % str(e))
                 return
@@ -3974,7 +3976,7 @@ class App(QtCore.QObject):
                     obj.mirror('Y', [px, py])
                     obj.plot()
                     self.object_changed.emit(obj)
-
+                self.inform.emit("[success] Flip on X axis done.")
             except Exception as e:
                 self.inform.emit("[ERROR_NOTCL] Due of %s, Flip action was not executed." % str(e))
                 return
@@ -4021,6 +4023,7 @@ class App(QtCore.QObject):
                         sel_obj.rotate(-num, point=(px, py))
                         sel_obj.plot()
                         self.object_changed.emit(sel_obj)
+                    self.inform.emit("[success] Rotation done.")
                 except Exception as e:
                     self.inform.emit("[ERROR_NOTCL] Due of %s, rotation movement was not executed." % str(e))
                     return
@@ -4053,6 +4056,7 @@ class App(QtCore.QObject):
                     obj.skew(num, 0, point=(xminimal, yminimal))
                     obj.plot()
                     self.object_changed.emit(obj)
+                self.inform.emit("[success] Skew on X axis done.")

     def on_skewy(self):
         self.report_usage("on_skewy()")
@@ -4082,6 +4086,7 @@ class App(QtCore.QObject):
                     obj.skew(0, num, point=(xminimal, yminimal))
                     obj.plot()
                     self.object_changed.emit(obj)
+                self.inform.emit("[success] Skew on Y axis done.")

     def delete_first_selected(self):
         # Keep this for later
@@ -4729,9 +4734,44 @@ class App(QtCore.QObject):
         elif type(obj) == FlatCAMCNCjob:
             obj.on_exportgcode_button_click()

+    def on_view_source(self):
+
+        try:
+            obj = self.collection.get_active()
+        except:
+            self.inform.emit("[WARNING_NOTCL] Select an Gerber or Excellon file to view it's source.")
+
+        # add the tab if it was closed
+        self.ui.plot_tab_area.addTab(self.ui.cncjob_tab, "Code Editor")
+        # first clear previous text in text editor (if any)
+        self.ui.code_editor.clear()
+
+        # Switch plot_area to CNCJob tab
+        self.ui.plot_tab_area.setCurrentWidget(self.ui.cncjob_tab)
+
+        # then append the text from GCode to the text editor
+        file = StringIO(obj.source_file)
+        try:
+            for line in file:
+                proc_line = str(line).strip('\n')
+                self.ui.code_editor.append(proc_line)
+        except Exception as e:
+            log.debug('App.on_view_source() -->%s' % str(e))
+            self.inform.emit('[ERROR]App.on_view_source() -->%s' % str(e))
+            return
+
+        self.ui.code_editor.moveCursor(QtGui.QTextCursor.Start)
+
+        self.handleTextChanged()
+        self.ui.show()
+
+        # if type(obj) == FlatCAMGerber:
+        #     self.on_file_exportdxf()
+        # elif type(obj) == FlatCAMExcellon:
+        #     self.on_file_exportexcellon()
+
     def obj_move(self):
         self.report_usage("obj_move()")
-
         self.move_tool.run()

     def on_fileopengerber(self):

FlatCAMGUI.py

@@ -292,6 +292,11 @@ class FlatCAMGUI(QtWidgets.QMainWindow):
         # Separator
         self.menuoptions.addSeparator()

+        self.menuoptions_view_source = self.menuoptions.addAction(QtGui.QIcon('share/source32.png'),
+                                                                                "View source\tALT+S")
+        # Separator
+        self.menuoptions.addSeparator()
+
         ### View ###
         self.menuview = self.menu.addMenu('&View')
         self.menuviewenable = self.menuview.addAction(QtGui.QIcon('share/replot16.png'), 'Enable all plots\tALT+1')
@@ -419,7 +424,7 @@ class FlatCAMGUI(QtWidgets.QMainWindow):
         self.menuprojectdisable = self.menuproject.addAction(QtGui.QIcon('share/clear_plot32.png'), 'Disable Plot')
         self.menuproject.addSeparator()
         self.menuprojectgeneratecnc = self.menuproject.addAction(QtGui.QIcon('share/cnc32.png'), 'Generate CNC')
-        self.menuproject.addSeparator()
+        self.menuprojectviewsource = self.menuproject.addAction(QtGui.QIcon('share/source32.png'), 'View Source')

         self.menuprojectedit = self.menuproject.addAction(QtGui.QIcon('share/edit_ok32.png'), 'Edit')
         self.menuprojectcopy = self.menuproject.addAction(QtGui.QIcon('share/copy32.png'), 'Copy')
@@ -999,6 +1004,10 @@ class FlatCAMGUI(QtWidgets.QMainWindow):
 			<td height="20"><strong>ALT+R</strong></td>
 			<td>&nbsp;Transformations Tool</td>
 		</tr>
+        <tr height="20">
+			<td height="20"><strong>ALT+S</strong></td>
+			<td>&nbsp;View File Source</td>
+		</tr>
 		<tr height="20">
 			<td height="20"><strong>ALT+U</strong></td>
 			<td>&nbsp;Cutout PCB Tool</td>
@@ -1294,8 +1303,8 @@ class FlatCAMGUI(QtWidgets.QMainWindow):
         self.code_editor.setStyleSheet(stylesheet)

         self.buttonPreview = QtWidgets.QPushButton('Print Preview')
-        self.buttonPrint = QtWidgets.QPushButton('Print CNC Code')
-        self.buttonFind = QtWidgets.QPushButton('Find in CNC Code')
+        self.buttonPrint = QtWidgets.QPushButton('Print Code')
+        self.buttonFind = QtWidgets.QPushButton('Find in Code')
         self.buttonFind.setFixedWidth(100)
         self.buttonPreview.setFixedWidth(100)
         self.entryFind = FCEntry()
@@ -1309,8 +1318,8 @@ class FlatCAMGUI(QtWidgets.QMainWindow):
             "When checked it will replace all instances in the 'Find' box\n"
             "with the text in the 'Replace' box.."
         )
-        self.buttonOpen = QtWidgets.QPushButton('Open CNC Code')
-        self.buttonSave = QtWidgets.QPushButton('Save CNC Code')
+        self.buttonOpen = QtWidgets.QPushButton('Open Code')
+        self.buttonSave = QtWidgets.QPushButton('Save Code')

         self.cncjob_tab_layout.addWidget(self.code_editor, 0, 0, 1, 5)

@@ -1711,6 +1720,11 @@ class FlatCAMGUI(QtWidgets.QMainWindow):
                     self.app.transform_tool.run()
                     return

+                # Transformation Tool
+                if key == QtCore.Qt.Key_S:
+                    self.app.on_view_source()
+                    return
+
                 # Cutout Tool
                 if key == QtCore.Qt.Key_U:
                     self.app.cutout_tool.run()

FlatCAMObj.py

@@ -422,6 +422,9 @@ class FlatCAMGerber(FlatCAMObj, Gerber):

         self.apertures_row = 0

+        # store the source file here
+        self.source_file = ""
+
         # assert isinstance(self.ui, GerberObjectUI)
         # self.ui.plot_cb.stateChanged.connect(self.on_plot_cb_click)
         # self.ui.solid_cb.stateChanged.connect(self.on_solid_cb_click)
@@ -1092,6 +1095,9 @@ class FlatCAMExcellon(FlatCAMObj, Excellon):
         # variable to store the distance travelled
         self.travel_distance = 0.0

+        # store the source file here
+        self.source_file = ""
+
         self.multigeo = False

     @staticmethod
@@ -4809,7 +4815,7 @@ class FlatCAMCNCjob(FlatCAMObj, CNCjob):

     def on_modifygcode_button_click(self, *args):
         # add the tab if it was closed
-        self.app.ui.plot_tab_area.addTab(self.app.ui.cncjob_tab, "CNC Code Editor")
+        self.app.ui.plot_tab_area.addTab(self.app.ui.cncjob_tab, "Code Editor")

         # delete the absolute and relative position and messages in the infobar
         self.app.ui.position_label.setText("")
@@ -4821,7 +4827,7 @@ class FlatCAMCNCjob(FlatCAMObj, CNCjob):
         preamble = str(self.ui.prepend_text.get_value())
         postamble = str(self.ui.append_text.get_value())
         self.app.gcode_edited = self.export_gcode(preamble=preamble, postamble=postamble, to_file=True)
-        # print(self.app.gcode_edited)
+
         # first clear previous text in text editor (if any)
         self.app.ui.code_editor.clear()


ObjectCollection.py

@@ -504,6 +504,8 @@ class ObjectCollection(QtCore.QAbstractItemModel):
         sel = len(self.view.selectedIndexes()) > 0
         self.app.ui.menuprojectenable.setEnabled(sel)
         self.app.ui.menuprojectdisable.setEnabled(sel)
+        self.app.ui.menuprojectviewsource.setEnabled(sel)
+
         self.app.ui.menuprojectcopy.setEnabled(sel)
         self.app.ui.menuprojectedit.setEnabled(sel)
         self.app.ui.menuprojectdelete.setEnabled(sel)
@@ -514,6 +516,7 @@ class ObjectCollection(QtCore.QAbstractItemModel):
             self.app.ui.menuprojectgeneratecnc.setVisible(True)
             self.app.ui.menuprojectedit.setVisible(True)
             self.app.ui.menuprojectsave.setVisible(True)
+            self.app.ui.menuprojectviewsource.setVisible(True)

             for obj in self.get_selected():
                 if type(obj) != FlatCAMGeometry:
@@ -522,6 +525,8 @@ class ObjectCollection(QtCore.QAbstractItemModel):
                     self.app.ui.menuprojectedit.setVisible(False)
                 if type(obj) != FlatCAMGeometry and type(obj) != FlatCAMExcellon and type(obj) != FlatCAMCNCjob:
                     self.app.ui.menuprojectsave.setVisible(False)
+                if type(obj) != FlatCAMGerber and type(obj) != FlatCAMExcellon:
+                    self.app.ui.menuprojectviewsource.setVisible(False)
         else:
             self.app.ui.menuprojectgeneratecnc.setVisible(False)


ObjectUI.py

@@ -1338,9 +1338,9 @@ class CNCObjectUI(ObjectUI):
         self.custom_box.addLayout(h_lay)

         # Edit GCode Button
-        self.modify_gcode_button = QtWidgets.QPushButton('Edit CNC Code')
+        self.modify_gcode_button = QtWidgets.QPushButton('View CNC Code')
         self.modify_gcode_button.setToolTip(
-            "Opens TAB to modify/print G-Code\n"
+            "Opens TAB to view/modify/print G-Code\n"
             "file."
         )


README.md

@@ -9,6 +9,11 @@ CAD program, and create G-Code for Isolation routing.

 =================================================

+17.02.2019
+
+- changed some status bar messages
+- New feature: added the capability to view the source code of the Gerber/Excellon file that was loaded into the app. The file is also stored as an object attribute for later use. THe view option is in the project context menu and in Menu -> Options -> View Source
+
 16.02.2019

 - added the 'Save' menu entry to the Project context menu, for CNCJob: it will export the GCode.

camlib.py

@@ -2185,6 +2185,8 @@ class Gerber (Geometry):
             for gline in glines:
                 line_num += 1

+                self.source_file += gline + '\n'
+
                 ### Cleanup
                 gline = gline.strip(' \r\n')
                 # log.debug("Line=%3s %s" % (line_num, gline))
@@ -3469,6 +3471,8 @@ class Excellon(Geometry):
                 line_num += 1
                 # log.debug("%3d %s" % (line_num, str(eline)))

+                self.source_file += eline
+
                 # Cleanup lines
                 eline = eline.strip(' \r\n')

@@ -3819,7 +3823,7 @@ class Excellon(Geometry):
                                     self.drills.append({'point': Point((coordx, coordy)), 'tool': current_tool})
                                     repeat -= 1
                             repeating_x = repeating_y = 0
-                            log.debug("{:15} {:8} {:8}".format(eline, x, y))
+                            # log.debug("{:15} {:8} {:8}".format(eline, x, y))
                             continue

                     ## Coordinates with period: Use literally. ##
@@ -3901,7 +3905,7 @@ class Excellon(Geometry):
                                     self.drills.append({'point': Point((coordx, coordy)), 'tool': current_tool})
                                     repeat -= 1
                             repeating_x = repeating_y = 0
-                            log.debug("{:15} {:8} {:8}".format(eline, x, y))
+                            # log.debug("{:15} {:8} {:8}".format(eline, x, y))
                             continue

                 #### Header ####
@@ -4004,7 +4008,6 @@ class Excellon(Geometry):
             # is finished since the tools definitions are spread in the Excellon body. We use as units the value
             # from self.defaults['excellon_units']
             log.info("Zeros: %s, Units %s." % (self.zeros, self.units))
-
         except Exception as e:
             log.error("Excellon PARSING FAILED. Line %d: %s" % (line_num, eline))
             msg = "[ERROR_NOTCL] An internal error has ocurred. See shell.\n"

flatcamTools/ToolTransform.py

@@ -595,7 +595,7 @@ class ToolTransform(FlatCAMTool):
                         # add information to the object that it was changed and how much
                         sel_obj.options['rotate'] = num

-                    self.app.inform.emit('Object(s) were rotated ...')
+                    self.app.inform.emit('[success]Rotate done ...')
                     self.app.progress.emit(100)

                 except Exception as e:
@@ -656,7 +656,7 @@ class ToolTransform(FlatCAMTool):
                                 else:
                                     obj.options['mirror_y'] = True
                                 obj.plot()
-                                self.app.inform.emit('Flipped on the Y axis ...')
+                                self.app.inform.emit('[success]Flip on the Y axis done ...')
                             elif axis is 'Y':
                                 obj.mirror('Y', (px, py))
                                 # add information to the object that it was changed and how much
@@ -666,9 +666,8 @@ class ToolTransform(FlatCAMTool):
                                 else:
                                     obj.options['mirror_x'] = True
                                 obj.plot()
-                                self.app.inform.emit('Flipped on the X axis ...')
+                                self.app.inform.emit('[success]Flip on the X axis done ...')
                             self.app.object_changed.emit(obj)
-
                     self.app.progress.emit(100)

                 except Exception as e:
@@ -715,7 +714,7 @@ class ToolTransform(FlatCAMTool):
                                 obj.options['skew_y'] = num
                             obj.plot()
                             self.app.object_changed.emit(obj)
-                    self.app.inform.emit('Object(s) were skewed on %s axis ...' % str(axis))
+                    self.app.inform.emit('[success]Skew on the %s axis done ...' % str(axis))
                     self.app.progress.emit(100)

                 except Exception as e:
@@ -771,7 +770,7 @@ class ToolTransform(FlatCAMTool):
                             obj.options['scale_y'] = yfactor
                             obj.plot()
                             self.app.object_changed.emit(obj)
-                    self.app.inform.emit('Object(s) were scaled on %s axis ...' % str(axis))
+                    self.app.inform.emit('[success]Scale on the %s axis done ...' % str(axis))
                     self.app.progress.emit(100)
                 except Exception as e:
                     self.app.inform.emit("[ERROR_NOTCL] Due of %s, Scale action was not executed." % str(e))
@@ -816,7 +815,7 @@ class ToolTransform(FlatCAMTool):
                                 obj.options['offset_y'] = num
                             obj.plot()
                             self.app.object_changed.emit(obj)
-                    self.app.inform.emit('Object(s) were offseted on %s axis ...' % str(axis))
+                    self.app.inform.emit('[success]Offset on the %s axis done ...' % str(axis))
                     self.app.progress.emit(100)

                 except Exception as e:

make_win.py

@@ -73,7 +73,7 @@ else:
         excludes=['scipy', 'pytz'],
         # packages=['OpenGL','numpy','vispy','ortools','google']
         # packages=['numpy', 'rasterio']  # works for Python 3.7
-        packages = ['opengl', 'numpy', 'google', 'rasterio'] # works for Python 3.6.5 and Python 3.7.1
+        packages = ['opengl', 'numpy', 'rasterio'] # works for Python 3.6.5 and Python 3.7.1

     )
